FTTB FTTX Mini Fiber Optic PLC Splitter 1x12 With SC APC Connector

Product Description

FTTB FTTX Mini Fiber Optic PLC Splitter 1x12 With SC APC Connector

Fiber Optic PLC Splitter mini module 1x12 with SC/APC connector

Fiber optic splitter is passive optical device that enables a light signal on an optical fiber to be distributed among two or more fibers.

Whenever the light beam transmitted in a network needs to be divided into two or more light beams, fiber optic splitters are used.

When the light signal is transmitted in a single-mode fiber, the light energy cannot entirely concentrate in the fiber core. A small amount of energy will be spread through the cladding of the fiber. If two fibers are close enough to each other, the transmitting light in an optical fiber can enter into another optical fiber. Therefore, the reallocation technique of optical signal can be achieved in multiple fibers. And this is how fiber optic splitter comes into being.

Here are the details of 1x12 mini module fiber optic splitter:

Features:

• Low insertion loss
• Stable polarization
• Compact design
• Excellent channel uniformity
• High stability and reliability
• Telcordia GR.1209 and GR.1221

Appliacation:

• FTTH
• CATV
• Passive optical network
• wired TV internet
• PON-FTTX network

Specifications:

Note: The above IL is without the connector parameters.
          1XN with connector optical splitter insertion loss in the above requirements in addition to 1X2 increase does not exceed 0.2dB, the remaining increase does not exceed 0.3dB.

Ordering information:

Advantages Of PLC Optical Splitter

1. Adopt high strength stainless steel, pass salt spray test

2. Ferrule core is less than 0.2um

3. Adopt 100% new raw material, ROHS compliance

4. Low Insertion loss

5. Low PDL Compact Design

6. Good channel-to-channel uniformity

7. Wide Operating Wavelength: from 1260nm to 1650nm

8. Wide Operating Temperature: from -40℃ to 85℃
