CWDM Mux Demux
>
Optical CWDM Mux Demux Rack Type

Optical CWDM Mux Demux Rack Type

Brand Name: Seacent
Model Number: Rack type CWDM
MOQ: Negotiable
Price: Negotiable
Payment Terms: L/C, T/T
Detail Information
Place of Origin:
Guangdong,China
Certification:
ISO9001,ROHS
Product Name::
Mux Demux CWDM
Type:
Rack Type CWDM
Channel Wavelength:
1270~1610nm
Center Wavelength Accuracy:
±0.5nm
Channel Spacing:
20nm
Channel Passband(@ -0.5dbbandwidth):
>14nm
Connector:
LC/APC Or Customized
Operating Temperature:
-20 ~+70°C
High Light:

Mux Demux CWDM

,

Rack CWDM Mux Demux

,

Optical CWDM Mux Demux

Product Description

Optical Mux Demux CWDM / Rack Type WDM Fiber Optic Multiplexer



Mux Demux CWDM feature



High isolation

Low PDL

Compact design

Good channel-to-channel consistency

Wide operating wavelength: 1270-1610nm

Wide working temperature: -20 ° C ~ 70 ° C

High reliability and stability



Mux Demux CWDM Application field



CWDM system

PON network

Cable chain



Mux Demux CWDM technical parameter



parameter 4 channels 6 channels 8 channels
Center wavelength(nm) ITU or ITU+1(Customizable starting wavelength)
Product Features Mux orDemux or Mux&Demux
Channel wavelength (nm) 1270~1610
Center wavelength accuracy (nm) ±0.5
Channel spacing (nm) 20
Channel passband(@ -0.5dbbandwidth(nm) >14
Insertion loss(dB) ≤1.4 ≤2.6 ≤3.0
Channel uniformity(dB) ≤0.5 ≤0.5 ≤0.5
Channel ripple(dB) 0.3
Isolation(dB) Adjacent >30 >30 >30
Isolation (dB) Non adjacent >40 >40 >40
Polarization dependent loss(dB) <0.2
Polarization mode dispersion(PS) <0.1
Directionality(dB) >50
Return loss(dB) >45
Connector type LC/APC or customized
Maximum power(mW) 500
Operating temperature(℃) -20~70
Storage temperature(℃) -40~85
Package type(mm) LGX,Box, rack or customer designation
Package size(mm)

LGX:201x256x44 or 155x100x29

Box:100x80x10 or 120x80x18 or 141x120x28

rack :1U: 484x260x44 or 2U: 482x260x88



Mux Demux CWDM Details



Optical CWDM Mux Demux Rack Type 0



Business advantage



Service:



(1) Experience in serving large customers for more than 8 years

(2) Independently provide product solutions and packaging solutions for customers

(3) Have strong strategic partners



Technology:



(1) Professionally engaged in high-precision packaging production of optical devices for 15 years

(2) 15 years of technical team

(3) Have their own core technology



Detailed parameters
