| Brand Name: | Seacent |
| Model Number: | Single Mode Duplex |
| MOQ: | 1 piece |
| Price: | USD 0.57~0.85 per piece |
| Supply Ability: | 150,000 pieces |
Professional FC To LC Fiber Patch Cord Single Mode Duplex ROHS Approved
What is a patch cord:
Fiber Optic Patch Cord is very important of optical network.they have same or different connectors which are installed on the end of fiber optic cable. The Fiber Optic Patch cord series comes with a comprehensive collection of lengths and connectors to meet your demand for the deployment.
Fiber optic patch cord is constructed from a core with a high refractive index, surrounded by a coating with a low refractive index, that is strengthened by aramid yarns and surrounded by a protective jacket. Transparency of the core permits transmission of optic signals with little loss over great distances. The coating's low refractive index reflects light back into the core, minimizing signal loss. The protective aramid yarns and outer jacket minimizes physical damage to the core and coating.
Technical parameter:
| Connector Type | SC/UPC-SC/UPC |
| Model | Single mode |
| Fiber Count | Duplex |
|
Fiber type |
G657A1 or customed |
|
Insertion loss(dB) |
≤0.3 |
|
Return loss(dB) |
≥55 |
|
Repeatability(dB) |
≤0.1 |
|
Interchangeability(dB) |
≤0.2 |
|
Number of plugs(frequency) |
≥1000 |
|
Tensile strength (N) |
≥70 |
|
Durability (dB) |
≤0.2 |
|
Working temperature (°C) |
-40℃- 85℃ |
|
Storage temperature (°C) |
-40℃- 85℃ |
Ferrule technical parameters:
|
description |
Single mode |
Multi mode |
|
length |
(10.50±0.05)nm |
(10.50±0.01)nm |
|
Outer diameter |
(2.4990±0.005)nm |
(2.4990±0.001)nm |
|
inside diameter |
(0.125±0.001)nm |
(0.126±0.129)nm |
|
Concentricity |
≤1.0 |
≤4.0 |
Features:
Applications:
Buy Fiber Optic Patch Cord
Ordering information:
|
Connector type |
Casing color |
Fiber type |
Cable diameter |
Fiber length |
Cable type |
Casing material |
|
1=FC/APC 2=FC/UPC 3=SC/APC 4=SC/UPC 5=LC/APC 6=LC/UPC 7=ST 8=Customized |
1=yellow 2=Orange 3=Aqua blue S=Customized |
1=SM9/125 G652D 2=SM9/125 G657A 3=MM50/125 OM3 4=MM62.5/125 OM1 S=Customized |
1=0.9mm 2=2.0mm 3=3.0mm |
0=0.5m 1=1.0m 2=1.5m 3=2.0m S=Customized |
1=Single core 2=Double core 3=waterproof 4=Branch 5=With fiber 6=Bundle |
1=PVC 2=LSZH 3=OFNR |
|
|
