Micro Type SC APC 1x2 Optical Splitter For Passive Optical Network
Contact Person : Mike nie
Phone Number : 8613713851846
WhatsApp : +8613713851846
| Minimum Order Quantity : | 1 piece | Delivery Time : | 5-8 work days |
|---|---|---|---|
| Payment Terms : | L/C, T/T | Supply Ability : | 100,000 pieces per month |
| Place of Origin: | Guangdong , China | Brand Name: | Seacent |
|---|---|---|---|
| Certification: | ISO9001 , ROHS | Model Number: | 2x2 mini module |
|
Detail Information |
|||
| Product Name: | 2x8 Plc Splitter | Connector: | SC/APC |
|---|---|---|---|
| Return Loss: | ≥55 DB | Insertion Loss: | ≤4.2 DB |
| PDL: | ≤ 0.25 DB | Directionality: | ≥55 DB |
| High Light: | 2x8 Micro Fiber Optic PLC Splitter,55dB Fiber Optic PLC Splitter,2x8 Micro PLC Splitter |
||
Product Description
High Stability 2x8 Micro Fiber Optic PLC Splitter With Compact Design
Fiber Optic PLC Splitter 2x2 micro type with SC/APC connector
PLC splitter or planar lightwave circuit splitter is a passive component that has the special waveguide made of planar silica, quartz or other materials. It is employed to split a strand of optical signal into two or more strands
Seacent Photonics offers excellent performance PLC splitter .Here are the details of 2x2 micro type fiber optic splitter:
Features:
Specifications:
| Item | Parameter |
|
IL(dB) |
≤4.2 |
|
Uniformity (dB) |
≤0.8 |
|
PDL (dB) |
≤0.25 |
|
RL(dB) |
≥55 |
|
Directionality (dB) |
≥55 |
|
Fiber length (m) |
1.0 or customized |
|
Temperature stability (dB) |
-40℃- 85℃(≤0.5) |
|
Working temperature |
40℃- 85℃ |
|
Fiber type |
G657A1 or customized |
Note: The above IL is without the connector parameters.
2XN with connector optical splitter insertion loss increased by no more than 0.3dB in the above requirements.
Ordering information:
|
Product type |
Inlet and exit diameter |
Inlet and fiber length |
size |
|
1XN or 2XN 0102=1X2 0103=1X3 0104=1X4 0105=1X5 0106=1X6 0107=1X7 0108=1X8 0112=1X12 0116=1X16 0124=1X24 0132=1X32 0164=1X64 1128=1X128 |
2=0.9mm |
0=0.5M 1=1.0M 2=1.5M 3=2.0M 4=2.5M S=Customized |
2x2 to 4x7x60mm 2x8
2x12 to 4x12x60 mm 2x16
2x24 to 6x20x80 mm 2x32
2x64 6x40x100 mm |
