24F MPO-LC Staggered Harness Cable
  • name
  • name

24F MPO-LC Staggered Harness Cable

Detail Information
Product Description
Detail Information
Highlight:

24F MPO-LC fiber optic cable

,

MPO-LC staggered harness cable

,

fiber optic patch cord with warranty

Product Description

24F MPO‑LC Staggered Harness Cable

This 24‑fiber harness assembly features an MPO (Female) connector on one end and 12 LC Duplex connectors (or 24 LC Simplex / 12 LC Uniboot depending on configuration) on the opposite end, with staggered sub‑cable lengths for optimized cable management.

Specifically engineered for 40G QSFP+ PLR4 to 10G SFP+ LR direct connections, as well as 100GBASE‑SR10 CXP/CFP and 100GBASE‑LR4 interconnect solutions, this harness cable supports 10/40/100G high‑density data center environments. It is ideal for linking (12) SFP+ transceivers to an MPO adapter panel and MPO trunk cabling.

The staggered design saves valuable rack space, reduces bend radius strain, and simplifies cable routing in dense patching areas—making it a practical choice for space‑constrained data centers seeking efficient, trouble‑free deployment.

Key Features:

  • Low insertion loss and high return loss

  • Cost‑effective mass‑termination solution

  • Available in low‑loss and standard‑loss versions for SM and MM applications

  • Excellent repeatability and interchangeability

Specification:

Items Single mode (APC ) Multimode (PC)
Insertion loss (MPO)



Standard loss:≤0.75dB(max), ≤0.50dB(Typical)


Low loss:≤0.35dB(max), ≤0.20dB(Typical)

Standard loss:≤0.6dB(max),

≤0.50(Typical)


Low loss:≤0.35dB(max) ,

≤0.20dB(Typical)
Return loss(MPO) ≥60dB ≥25dB
Durability <0.3dBtypical change, 200 matings
Interchangeability ≤0.2dB
Tensile strength >70N
Operating Temperature -40 to + 85°C
