| Brand Name: | Seacent |
| Model Number: | 12-color beam |
| MOQ: | 1 piece |
| Payment Terms: | L/C, T/T, D/P |
Fiber Pigtail 12-color beam LC connector UPC polish high return loss
Technical parameter:
| Connector Type | FC,SC,LC |
| Fiber Cable Type | 12 ribbon fiber, flat cable, round cable or customer specified |
| Parameters | UPC,APC |
| Insertion Loss | < 0.3 dB |
| Return Loss | >55 dB |
| Working Wavelength | 1310,1550 |
| Fiber Type | G657A1 or customized |
| Reliability | < 0.1 dB |
| Tensile strength | >20 dB |
| Working Temperature | -40~85C |
| Storage Temperature | -40~85C |
Ferrule technical parameters:
| description | Single mode | Multi mode |
| length | (10.50±0.05)nm | (10.50±0.01)nm |
| Outer diameter | (2.4990±0.005)nm | (2.4990±0.001)nm |
| inside diameter | (0.125±0.001)nm | (0.126±0.129)nm |
| Concentricity | ≤1.0 | ≤4.0 |
Ordering information:
| Connector type | Casing color | Fiber type | Cable diameter | Fiber length | Cable type | Casing material |
|
1=FC/APC 2=FC/UPC 3=SC/APC 4=SC/UPC 5=LC/APC 6=LC/UPC 7=ST 8=Customized |
1=yellow 2=Orange 3=Aqua blue S=Customized |
1=SM9/125 G652D 2=SM9/125 G657A 3=MM50/125 OM3 4=MM62.5/125 OM1 S=Customized |
1=0.9mm 2=2.0mm 3=3.0mm |
0=0.5m 1=1.0m 2=1.5m 3=2.0m S=Customized |
1=Single core 2=Double core 3=waterproof 4=Branch 5=With fiber 6=Bundle |
1=PVC 2=LSZH 3=OF |
Description:
Fiber Optic Pigtails are essential when terminating cables within the splice enclosures. Purchasing pre-polished assemblies reduces the risk of poor connector termination.
Apart from the standard versions, we can also make customized pigtails that meet your needs. From industry-standard 62.5/125µm multimode over 9/125 µm Single-mode right the way up to state-of-the-art OM3 50/125 µm cable assemblies, we can supply them all.
Features:
Appliaction:
Business advantage
Service:
(1) Experience in serving large customers for more than 8 years
(2) Independently provide product solutions and packaging solutions for customers
(3) Have strong strategic partners
Research and development:
(1) Adhere to 5% of annual sales as technology research and innovation expenses
(2) Independent development chip
|
|
