Brand Name: | Seacent |
Model Number: | 6 channels |
MOQ: | 1 piece |
Payment Terms: | L/C, T/T, D/P |
Supply Ability: | 100,000 pieces per month |
Optical Fiber 4CH CCWDM Mux Demux With LC / APC Connector Type , High Stability
Description:
Seacent Photonics compact CWDM Modules feature free-space structure, high optical performance, small-sized package, and extremely low insertion loss. With these features, they dramatically relax the optical power budgets for your applications, allow datacom or telecom network applications to use low-cost uncooled lasers, and function in small-sized packages. Available from 4 to 18 channel configurations, the CCWDM can meet the expansion needs of any network. The module also simplifies inventory management since the same component serves as both a Mux and a Demux and can be used in the head end for outside plant. Compact and easy to install, the versatile compact CWDM module provides a simple and low-cost method for expanding bandwidth and increasing revenue from existing optical fiber.
Specifications:
Item | 4CH | 8CH | 18CH |
Center wavelength (nm) | ITU or ITU+1(Customizable starting wavelength) | ||
Product Features | Mux or Demux or Mux&Demux | ||
Channel wavelength (nm) | 1270~1610 | ||
Center wavelength accuracy (nm) | ±0.5 | ||
Channel pitch (nm) | 20 | ||
Insertion loss (dB) | ≤1.0 | ≤1.5 | ≤3.2 |
Channel uniformity (dB) | ≤0.5 | ≤0.5 | ≤0.5 |
Isolation adjacent (dB) | >30 | >30 | >30 |
Isolation Non-adjacent (dB) | >45 | >45 | >45 |
Polarization-dependent loss (dB) | <0.2 | ||
Polarization Mode Dispersion (PS) | <0.1 | ||
Directivity (dB) | >50 | ||
Return loss (dB) | >45 | ||
Connector type | LC/APC or customer specified | ||
Maximum power (mW) | 500 | ||
Working temperature (℃) | -5~70 | ||
Storage temperature (℃) | -40~85 | ||
Package (mm) | 44x25x6 or customer specified |
Remark:The above parameters do not contain connectors.
Features:
Application:
Business advantage
Product:
(1) High reliability, high stability, small size, low insertion loss
(2) 1*N 2*N multiple channel forms
(3) 1260-1650nm full-band operation
(4) Industrial working environment: -40 ° C - + 85 ° C
(5) ISO9001-2015 quality system, Telcordia GR-1209-CORE, GR-1221-CORE standard certificate
(6) Customization: can be customized according to customer requirements
(7) Product process: industry leading
